0F Series

Standard Features:
- Often, a lower initial cost
- Few worries about motor overheating during low speed operation
- No motor brushes to replace
- Very compact and lightweight when compared to other mechanical drives
- Simple design with few rotating components to wear or replace
- Easily serviced by semi-skilled personnel
- Low maintenance – doesn’t need to be cycled through its speed range to prevent component damage
- 2 year warranty – your assurance of satisfactory product performance
- Attaches to MGS “C”, “F”, and “K” units for additional speed reduction.
Specifications:
- HP Ratings: 0.5 to 10
- Output Speeds: 2180 to 311 RPM
- Speed Range: 5:1 or 7:1
- Output Torques: Up to 496 in.lb.
- NEMA C-Face Input: 56C through 215TC
- Stainless steel nameplate and hardware
- NEMA C-Face Output: 56C through 182/184TC
C_TD Series

Specifications:
- Horsepower ratings – from 1/2 to 10
- Output speeds – available from 1139 to 1.2 RPM
- Speed range – 5:1 to 7:1
- Output torques – up to 59,782 in.lbs.
- NEMA frames – from 56C to 215TC
F_TD Series

Specifications:
- Horsepower ratings – from 1/2 to 71/2
- Output speeds – available from 528 to .6 RPM
- Speed range – 5:1 to 7:1
- Output torques – up to 9,744 in.lbs.
- NEMA frames – from 56C to 215TC
K_TD Series

Specifications:
- Horsepower ratings – from 1/2 to 10
- Output speeds – available from 569 to .9 RPM
- Speed range – 5:1 to 7:1
- Output torques – up to 99,227 in.lbs.
- NEMA frames – from 56C to 215TC
