Standard Features: High tensile strength gray cast iron body. Load check on each spool. Hard chrome plated spool. Optional 4 Position Float on the 1st spool. Differential poppet style relief, adjustable from 1500 to 3000 psi (also available in low pressure version adjustable from 500 to 1500 psi). Power beyond and closed center capability. Reversible handle option.
STANDARD MODELS
RD512CA5A4B1: Single spool to 30GPM double acting cylinder spool spring center to neutral. Convertible to power beyond or closed center. 3/4˝ NPT inlet and outlet, 1/2˝ NPT working ports. Relief preset at 2000 PSI, adjustable 1500-3000 PSI. Made in the U.S.A.
RD512GG5A4B1: Single spool to 30 GPM double acting cylinder spool with 4th position float detent and spring center to neutral. Convertible to power beyond or closed center. 3/4˝ NPT inlet and outlet, 1/2˝ NPT working ports. Relief preset at 2000 PSI, adjustable 1500-3000 PSI. Made in the U.S.A.
RD522CCAA5A4B1: Two-spool to 25 GPM double acting cylinder spools, spring center to neutral. Convertible to power beyond or closed center. 3/4˝ NPT inlet and outlet, 1/2˝ NPT working ports. Relief preset at 2000 PSI, adjustable 1500-3000. Made in the U.S.A.
RD522GCGA5A4B1: Two-spool to 25 GPM double acting cylinder spool. First spool with 4th position float detent and spring center to neutral. 2nd spool spring center to neutral. Convertible to power beyond or closed center. 3/4˝ NPT inlet and outlet port, 1/2˝ NPT working ports. Relief preset at 2000 PSI, adjustable 1500-3000 PSI. Made in the U.S.A.
RD532CCCAAA5A4B1: Three spool to 25 GPM double acting cylinder spools spring center to neutral. 3/4˝ NPT inlet and outlet ports, 1/2˝ NPT working ports. Convertible to power beyond or closed center. Relief preset at 2000 PSI, adjustable 1500-3000 PSI. Made in the U.S.A.
RD532GCCGAA5A4B1: Three spool to 25 GPM double acting cylinder spools. 1st spool with 4th position float detent and spring center to neutral. 2nd and 3rd spools spring center to neutral. 3/4˝ NPT inlet and outlet ports, 1/2˝ NPT working ports. Convertible to power beyond or closed center. Relief preset at 2000 PSI, adjustable 1500-3000 PSI. Made in the U.S A.
