Enerpac offers a wide range of hydraulic torque wrench pumps, with electric or air motors to power single or double-acting hydraulic torque wrenches. Safe and efficient new Enerpac Z-Class ZU4T-series pumps with universal electric motor made especially for repetitive bolting tasks.
PMU-Series, Portable Electric Torque Wrench Pumps
Reservoir 0.5 – 1 gal.
Flow 20 in3/min.
Motor 0.5 hp
Max. Pressure 10,000 and 11,600 psi
- Enerpac portable electric torque wrench pumps features a powerful two-speed pump which is lightweight and easy to carry
- Standard heat exchanger package keeps pump cool under extreme use
- Glycerin filled gauge with scales reading in psi and bar
- Transparent overlays in Ft.lbs and Nm for all Enerpac torque wrenches provide a quick torque reference
- Universal motor for a high power-to-weight ratio; generates full pressure on as little as 50% of the rated line voltage
- Adjustable pressure relief valve for accurate torque adjustments and precise repeatability
ZU4-Series, Electric Torque Wrench Pumps
Reservoir Capacity 1 and 1.75 gal.
Flow 60 in3/min
Motor Size 1.7 hp
Max. Pressure 10,000 and 11,600 psi
View the Enerpac Z-Series video
- Enerpac electric torque wrench pumps feature Z-Class high-efficiency pump design; higher oil flow and bypass pressure, cooler running and requires 18% less current draw than comparable pumps
- Powerful 1.7 hp universal electric motor provides high power-to-weight ratio and excellent low-voltage operating characteristics
- High-strength, molded composite shroud protects motor and electrical components, while providing an ergonomic, non-conductive handle for easy transport
- Low-voltage pendant provides additional safety for the operator
- Valve technology reduces oil operating temperatures and withstands contaminants to increase pump reliability
- LCD readout provides pressure and torque display and a number of diagnostic and readout capabilities never before offered on a portable electric pump
- Auto cycle feature provides continuous cycle operation of the torque wrench as long as the advance button is pressed. (Pump can be used with or without auto cycle feature)
ZE-Series, Electric Torque Wrench Pumps
Reservoir 1.0 gal.
Flow 60 -120 in3/min.
Motor Size 1.5 – 3.0 hp
Max. Pressure 10,000 psi
- Enerpac electric torque wrench pumps feature Z-Class high-efficiency pump design; higher oil flow and bypass pressure, cooler running and requires 18% less current draw than comparable pumps
- Totally enclosed, fan-cooled industrial electric motors supply extended life and stand up to harsh industrial environments
- Low-voltage pendant provides additional safety for the operator
- High-strength, molded electrical enclosure protects electronics, power supplies and LCD readout from harsh environments
- LCD readout provides pressure and torque display and a number of diagnostic and readout capabilities never before offered on a portable electric pump
- Auto cycle feature provides continuous cycle operation of the torque wrench as long as the advance button is pressed (Pump can be used with or without auto cycle feature)
- Valve technology reduces oil operating temperatures and withstands contaminants to increase pump reliability
TQ-700, Lightweight Electric Torque Wrench Pump
Reservoir 1 gallon
Max. Pressure 10,000 psi
- Optimized flow technology delivers up to 50% faster bolting than competing pumps
- Compact and lightweight design fits through tight openings and provides easy handling
- Built-in protection for controls and gauge for job-site durability
- IP55 * rating for superior dust and water protection
- Advanced IEC Motor provides for quiet, continuous operation, high voltage tolerance, and low maintenance
- Simple pressure setting and convenient pendant control for hassle-free operation
PTA-Series, Compact Pneumatic Torque Wrench Pump
Reservoir 1 gal.
Flow 20 in3/min.
Max. Pressure 10,000 and 11,600 psi
- Enerpac compact pneumatic torque wrench pump provides two-stage power in a portable design
- Handle located directly over pump’s center of gravity for greater ease in carrying
- High bypass (1800 psi) for faster torque cycles
- High power-to-weight ratio suits all Enerpac torque wrenches
- Glycerine filled pressure gauge with scales reading in psi/bar
- Transparent overlays in Ft.lbs. and Nm for all Enerpac torque wrenches provide a quick torque reference
- Internal safety relief valve, factory preset
- 15 ft. air pendant assembly enables easy maneuvering at the job site
ZA4T-Series, Air Driven Torque Wrench Pumps
Reservoir 1 and 1.75 gal.
Flow at 10,000 psi 60 in3/min.
Max. Pressure 10,000 and 11,600 psi
- Enerpac air driven torque wrench pumps features Z-Class high efficiency pump design; higher oil flow and bypass pressure
- Two-speed pump operation and high by-pass pressure reduces cycle time for improved productivity
- Heat exchanger warms exhaust air to prevent freezing and cools the oil
- Ergonomic pendant allows remote operation up to 20 feet
- Glycerin filled pressure gauge with transparent overlays in Ft.lbs and Nm for Enerpac torque wrenches provide a quick torque reference
- Regulator-Filter-Lubricator with removable bowls and auto drain is standard
- Valve technology reduces oil operating temperatures and withstands contaminants to increase pump reliability
ZUTP-Series, Hydraulic Electric Tensioning Pumps
Reservoir 1 gallon
Flow 8.0 in3/min.
Max. Pressure 21,750 psi
- High efficiency Universal Motor draws lower amps for superior performance in remote locations
- Panel mounted 6-inch pressure gauge, with polycarbonate cover, for improved visibility and safety
- User adjustable valve for safe and precise pressure control
- Compact and lightweight design fi ts through tight openings and provides easy handling
- Safety relief valve limits output pressure for additional operator safety
ATP-Series, Ultra-High Pressure Air Pump
Reservoir 1 gallon
Flow 4 in3/min
Max. Pressure 21,750 psi
- General purpose, air driven ultra high pressure hydraulic pump unit for products requiring up to 21,750 psi hydraulic pressure
- Compact, lightweight, rugged steel frame for protection and easy handling of the hydraulic power unit
- Prelubricated pump element, does not require an airline lubricator
- Easily adjustable output pressure control
- Integrated and protected easy to read glycerin filled gauge
- Safety relief valve limits output pressure.
- Enerpac tensioning hand pump is a lightweight and portable high-pressure hand pump
- Two-speed pump operation displaces a larger volume of oil per stroke, reducing cycle times for many testing applications
- Includes a gauge and coupler for direct connection to GT-Series bolt tensioners
- Integrated relief valve set at 21,750 psi.
THC, THQ-Series, Torque Wrench Hoses
Lengths 19.5 – 39 ft
Max. Pressure 10,000 – 11,600 psi
- Thermoplastic torque wrench hoses
- Dual hoses, 19.5 and 39 feet long
- THQ-700-series with spin-on couplers for:
- 10,000 psi S and W-series torque wrenches
- Torque wrench pumps with suffix “Q”
- THC-700-series with lock-ring couplers for:
- 11,600 psi SQD and HXD-series torque wrenches
- Torque wrench pumps
HT, B-Series, Accessories for Bolt Tensioners and Pumps
Max. Pressure 21,750 psi
- Enerpac bolt tensioner and pump accessories include hoses and quick disconnect couplers
- 21,750 psi maximum operating pressure.
ST-Series, Bolting Tool-Pump Sets
Capacity 5 – 20 tons
Max. Pressure 10,000 psi
- Performance match tool-pump sets
- Performance match tool-pump sets
- Nut Splitter Sets – splits nuts quickly and safely in seconds
- Flange Spreader Sets – separate pipe flanges with ease, enabling efficient maintenance tasks
- Wedge Spreader Set – friction-free, smooth and parallel wedge movement without risk of spreading arm failure
- All sets include 6 feet safety hose HC-7206, gauge GP-10S and gauge adapter GA-2
