GC-9000 Series
Description
Our hydraulic power units are designed specifically to operate on AC electric power. Each power unit is a custom selected assembly consisting of a high performance hydraulic pump, reservoir, motor, internal relief valve, and load holding check valve. They can be controlled with remote valving or with optional NFPA D03 (D01) directional control valves (our 1300329 adapter manifold is required to mount directional control valves directly on the power units.) The power units can be coupled via suitable hydraulic lines to a wide range of operating mechanisms. They normally operate hydraulic cylinders, but can be used with any other hydraulic actuating device.
Specifications
All units have:
|
Additional options available:
- 1300329 – NFPA D03 (D01) Adapter Manifold for directional control valves
- 1300796 – 3 gallon cylindrical reservoir for vertical mount. Requires 1300804 tube kit.
- 1300688 – 5 GPM Two Stage High/Low Pump
AC HYDRAULIC POWER UNIT PERFORMANCE | ||||||||
NOMINAL GPM | MAXIMUM OPERATING PRESSURE | HP | MOTOR PHASE | VOLTS 60 HZ | RPM | Dim. A | Dim. B | Dim. C |
1/2 | 1500 | 1/2 | 1 | 115/230 | 1800 | 21.01˝ | 8.17˝ | 8.79˝ |
1/2 | 3000 | 1 | 1 | 115/230 | 1800 | 23.04˝ | 10.20˝ | 8.79˝ |
1 | 1500 | 1 | 1 | 115/230 | 1800 | 23.04˝ | 10.20˝ | 8.79˝ |
1-1/2 | 1000 | 1 | 1 | 115/230 | 1800 | 23.04˝ | 10.20˝ | 8.79˝ |
2 | 750 | 1 | 1 | 115/230 | 1800 | 23.04˝ | 10.20˝ | 8.79˝ |
1 | 1500 | 1 | 3 | 230/460 | 1800 | 21.23˝ | 8.39˝ | N/A |
2 | 750 | 1 | 3 | 230/460 | 1800 | 21.23˝ | 8.39˝ | N/A |
2 | 1500 | 2 | 3 | 230/460 | 3600 | 21.70˝ | 8.86˝ | N/A |
4 | 750 | 2 | 3 | 230/460 | 3600 | 21.70˝ | 8.86˝ | N/A |
