From the compact controls product line Rexroth also offers a wide range of insert type cartridge valves. Among them, the VMA valves family represent an interesting solution since they combine in one small insert cartridge the typical function of a direct acting relief valve and the anticavitation function through the check valve.
Thanks to the very limited size they are very suited for use in pumps, directional control valves as well as integrated circuits.
Various configurations in order to get different functions are available in the VMA family:
- Pressure relief and anticavitation function – fixed setting
- Pressure relief (without anticavitation) – fixed setting
- Anticavitation function only
- Pressure relief and anticavitation – adjustable setting
The insert type cartridge line also includes a variety of check valves, pressure compensated flow controls and hose burst valves.
| Pressure relief valves | Max Flow (l/min) | Max pressure (bar) |
| VMA1.025 | 30 | 210 |
| VMA1.050 | 60 | 380 |
| VMA1.060 | 75 | 380 |
| VMA1.080 | 90 | 400 |
| VMA1.180 | 180 | 400 |
| Pressure compensated, flow control valves | Max Flow (l/min) | Max pressure (bar) |
| SFC1 | 45 | 210 |
| VCD1 | 150 | 315 |
| Check valves | Max Flow (l/min) | Max pressure (bar) |
| VUH1 | 80 | 350 |
| VUB1 | 80 | 350 |
| Hose burst check valves | Max Flow (l/min) | Max pressure (bar) |
| VPN1 | 150 | 315 |
